Features:
Input Signal 4 to 20mA
Output Signal 4 to 20mA
Body Aluminium
IP Rating IP66
Electro Pnuematic linear positioner with 4-20mA input and output. Models to suit both Double Acting and Spring Return linear actuators. For actuators with greater than 180cm3 volume. Comes standard with 10 to 40mm feedback lever however other sizes are available upon request.
Input Signal | 4 to 20mA |
---|---|
Output SIgnal | 4 to 20mA |
Impedance | 250+/- 15Ω |
Supply Pressure | 1.4~7kgf/cm2 (20~200 psi) (Clean Dry Air Recommended) |
Air Connectiong | G 1/4" |
Gauge Connection | G 1/8" |
Conduit | G 1/2" |
Weather Protection | IP66 |
Ambient Temperature | -20°C to 70°C |
Linearity | ± 1.5% |
Hysteresis | 1.50% |
Sensitivity | 0.40% |
Air Consumption | 3LPM (Sup=1.4kgf/cm2, 20psi) |
Flow Capacity | 8LPM(Sup=1.4kgf/cm2, 20psi) |
Material | Aluminium Die Cast |
Weight | 2.7kg |
