SKU: APC-01

Pneumatic Pilot Check Valve

G1/8" Pilot Check Valve

$66.00

Inc GST
Sold Out
Make an Enquiry

This pilot check valve only allows air to flow through the valve in the presence of a pilot signal. Commonly used in applications where flow should only occur once another system (pilot) is activated.

Pilot Check Valve Symbol

Specification APC-01
Port Size G1/8”
Nominal Diameter 4mm
Pressure Range 0.5 to 10 BAR
Max Inlet Pressure 10 BAR
Medium Temperature -5 to 60°C
Body Die Cast Aluminium
Top Reinforced Plastic
Lubrication Not Required
Applicable Medium Air

Pilot Check Valve Dimensions

Size 1/8" BSP only
Function Pilot Check Valve
Body Aluminium
Pressure Range 0.5 to 10 BAR
Media Air

Others Also Bought

APC-01

Pneumatic Pilot Check Valve

Features:

Size 1/8" BSP only
Function Pilot Check Valve
Body Aluminium
Pressure Range 0.5 to 10 BAR
Media Air

Description:

This pilot check valve only allows air to flow through the valve in the presence of a pilot signal. Commonly used in applications where flow should only occur once another system (pilot) is activated.

Pilot Check Valve Symbol

Specification APC-01
Port Size G1/8”
Nominal Diameter 4mm
Pressure Range 0.5 to 10 BAR
Max Inlet Pressure 10 BAR
Medium Temperature -5 to 60°C
Body Die Cast Aluminium
Top Reinforced Plastic
Lubrication Not Required
Applicable Medium Air
.

Pneumatic Pilot Check Valve

APC-01

Dimensions:

Pilot Check Valve Dimensions

WARNING

These products are intended for use in industrial applications only. Do not use these products where pressures and temperatures can exceed those listed under ‘Technical Data’ and in our individual ‘Series’ data sheets. Before using these products with fluids other than these specified, for non-industrial applications, life-support systems, or other applications not within published specifications, consult Process Systems Pty Ltd. Through misuse, age, or malfunction, components used in industrial valve applications can fail in various modes. The system designer is warned to consider the failure modes of all component parts used in industrial valve applications and to provide adequate safeguards to prevent personal injury or damage to equipment in the event of such failure. System designers must provide a warning to the user in the system instructional manual if protection against a failure mode cannot be adequately provided. System designers and end users are cautioned to review specific warnings or specifications found in instruction sheets or labels packed or attached and shipped with the products. Our policy is one of continuous research and development. We therefore reserve the right to amend without notice the specifications given in this document or our individual ‘Series’ data sheets.
